    The following series of slides will provide information about the machine’s electrical system. The system is permissible and approved as explosion-proof under 30 CFR Part 18. The electrical system includes an alternator (source of power) located in the engine compartment, a headlight switch located in the operator’s compartment, and four headlights (two on each end of the machine). The electrical system of the machine needs to be checked at least weekly to ensure that it is maintained in accordance with applicable requirements.
